Ignite SX Series LED Lightbar 20 Inch Single Row Combo Beam
Description
Ignite SX Series Single Row LED Driving Lamp Lightbar 9 - 36 Volt 120 Watt. This robust lightbar features Integrated Electronic Thermal Management (ETM) to ensure optimal performance under extreme conditions. The housing is crafted from black powder-coated extruded 6063 aluminium, equipped with an integrated heat-sink and pressure equalizing vent for superior durability.
Designed for versatility, it includes dual mounting systems with bottom and side mount brackets. The cross slider bracket assembly allows for flexible positioning of the bottom brackets along the length of the bar. It comes with a 500mm lead and a 2-pin Deutsch plug, ensuring easy installation.
Safety is paramount with over and under voltage protection and reverse polarity protection. The lightbar is powered by 12 high-intensity Osram LEDs, providing exceptional brightness while being UV, water, and shock resistant. With a lifespan of 50,000 hours, this lightbar is built to last.
It meets ECE R112, R10, and CE standards, boasting an IP68 and IP69K rating for water and dust resistance. Operating temperature ranges from -40°C to +60°C, making it suitable for various environments. Backed by a 5-year warranty, you can trust its reliability.
Spare parts available include:
- INPB001 Licence Plate Mounting Bracket
- IBB50MM Round Bullbar Mounting Bracket 50mm
- IBB64MM Round Bullbar Mounting Bracket 64mm
- IBB76MM Round Bullbar Mounting Bracket 76mm
- IAS40MM 40mm Spacer Mounting Bracket
- IBB01 Back Mounting Bracket
- IBB02 Spare Bottom Mounting Bracket
With a combined spot (pencil) and flood (spread) beam pattern of 15 degrees and 35 degrees, this lightbar delivers 12,420 raw lumens, achieving 1 lux at 445m with a color temperature of 6,000K. Current draw is 7.9 amps at 12 volts and 3.9 amps at 24 volts, ensuring efficient power usage.
Utilizing proprietary polycarbonate TIR optical system reflector technology with a Lexan polycarbonate lens, it offers light transmittance greater than 95%.
Shop all lightbars.
